Send InquiryUltrasonic Cleaning Bath
About Ultrasonic Cleaning Bath
Specifications :
| Electric Supply | 170-245V, A.C, 50 Hz 1 phase. |
|---|---|
| Ultrasonic Power | As per Model |
| Ultrasonic Frequency | 33 OR 40 KHz +/- 3 KHz |
| Ultrasonic Generator | Micro Controller base Digital Timer. With latest MOSFET / IGBT base technology. With Auto Degassing facility. Automatic frequency tuning for maximum output Modular generator for easier modification/servicing. Digital Temp. Controller Pulse Sweep Power |
| Timer | Two Digit LED display 0 –90 minutes Timer with settable & on / off keys. |
| Temperature Control | Digital Temp/ Controller (Up to 50Ëš C with two Digit LED Display with settable. |
| Transducers | PZT Sandwich type, bonded on the base of S.S Tank, Crystal used of PZT4, of APC / Concord Make. High temp. & good quality wires for connection & epoxy for bonding of transducers are used. |
| Tank Clear Size | As per module |
| Tank MOQ | S.S 304 grade, 1.6mm thick & buffed form inside Tank Capacity |
| Drain Valve | 1/2″ Ball Valve is provided for cleaning the tank |
| Tank Housing MOQ | S.S 304 grade. |
| Accessory | Basket, lid, manual & power cord is provided (As per model/ Customer requirements) |
